TokenParser.h File Reference

#include "../../Defines.h"

Include dependency graph for TokenParser.h:

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Classes
struct	smStruct

Typedefs
typedef struct smStruct	SMStruct

Functions
void	parseQueryLine_mainModule (char *line)
	parses a line of text, The caller then uses queryMatchesName() to see if their name matches More...
boolean	queryMatchesName_mainModule (char *name)
boolean	stringIsQuery_mainModule (char *line)
	whether the stirng is a potential query More...
void	setup_tokenParser_mainModule ()
	setup for the token parser (really just for testing) More...
char *	semanticMarkerToJSON_TokenParser (char *semanticMarker)
char *	parseSM_For_UUID_Flownum (char *semanticMarker)
	before 1355313 now 1355169 More...
SMStruct	parseSMAddress (char *str)
	2.11.26 moved here from ChainButtonClassType More...
char *	parseDOCFOLLOW (char *str)

Typedef Documentation

SMStruct

typedef struct smStruct SMStruct

2.11.26 Rainier out in spring like day. refactor, moving parsing from Chain to here.. 2.10.26 NICE day out .. struct for returning a parsed SM address syntax: uuid.flow(set,val,dev)

Function Documentation

parseDOCFOLLOW()

char * parseDOCFOLLOW

(

char *

str

)

2.11.26 Lincoln's birthday, Puppies going home to Auburn, Nice Day out.. return the uuid.flownum (if any) search for 'uuid=<uuid>&" and "flow=<flow> [& or }" return NULL if not matching NOTE: no storage is created but the buffer returned is REUSED

strstr() function locates the first occurrence of the null-terminated string needle in the null-terminated string

find uuid

now find flow

follow = } or & (if more args)

Definition at line 1018 of file TokenParser.cpp.

Here is the caller graph for this function:

parseQueryLine_mainModule()

void parseQueryLine_mainModule

(

char *

line

)

parses a line of text, The caller then uses queryMatchesName() to see if their name matches

parses a line of text, The caller then uses queryMatchesName() to see if their name matches

NOTE: doesn't support the BLE addresses like: DevQuery: !M5Laybrinth & !84:cc:a8:7a:f6:aa

initialize the variables for parsing this line

if no query params, then make it an identifier and exit

if parsing still then add to identifier

start a new identifier..

init the identifier

else not valid identifier (so a follow..)

done parsing if not a valid identifier character

finishIdNeeded is before pushing another token, unless a not or wildcard

now classify this char if an identifier modifier

! and * belong to the identifier object if a modifier of ident (~ or *) then push the token, and process the identifier

an operator or space if inside an identifier, finish it first

process the token

& and | are expression modifiers

if end of line, and was parsing an identifier .. then finish

Definition at line 258 of file TokenParser.cpp.

Here is the call graph for this function:

parseSM_For_UUID_Flownum()

char * parseSM_For_UUID_Flownum

(

char *

semanticMarker

)

before 1355313 now 1355169

3.29.25 Raiiiinier Beeer movie last night add returning a UUID.FLOWNUM if valid, or nil if nota

3.29.25 Raiiiinier Beeer movie last night add returning a UUID.FLOWNUM if valid, or nil if nota note "flow" .. not flownum uuid=x&flow=y& .. flownum could be the last .. so end-of-line

2.11.26 REFACTORinto the version below...

Definition at line 843 of file TokenParser.cpp.

Here is the call graph for this function:

Here is the caller graph for this function:

parseSMAddress()

SMStruct parseSMAddress

(

char *

str

)

2.11.26 moved here from ChainButtonClassType

2.10.26 Sunny Clear, Mountain, parse the address syntax: uuid.flow(set,val,dev) NOTE: THis creates storage for the 3 components

return value

syntax: uuid.flow(set,val,dev)

now find the pieces starting at 1 past paren

now the valString

get rid of the " " version

now the dev follow = )

Definition at line 947 of file TokenParser.cpp.

Here is the call graph for this function:

Here is the caller graph for this function:

queryMatchesName_mainModule()

boolean queryMatchesName_mainModule

(

char *

name

)

now need to process the token tree to see if name1 and name2 match the query eg. ! name & name2 ... wildcards after name make it slightly complicated SO: look for wildcards before and after, and the id. then decide if that matches before the boolean and notmodifier applied

basically for each identifier in the query, the names (1&2) have to be compared each time..

what the last boolean_enum was..

the result of A <> B

Definition at line 424 of file TokenParser.cpp.

Here is the call graph for this function:

Here is the caller graph for this function:

semanticMarkerToJSON_TokenParser()

char * semanticMarkerToJSON_TokenParser

(

char *

semanticMarker

)

3.23.25 rainy weekend create a JSON string from the SemanticMarker https://semanticmarker.org/bot/setdevice/scott@konacurrents.com/PASS/M5AtomSocket/socket/on} Create a JSON knowing the "bot" syntax, eg. setdevice/USER/PASS/device/<set>/<flag> and others like set etc. Maybe not 'dev' here. Others cmddevice/USER/PASS return: {'set':<set>,"dev': Supports these for now: GET /set/{username}/{password}/{command}/{value} GET /send/{username}/{password}/{request} only support 'device' ones GET /setdevice/{username}/{password}/{devicename}/{command}/{value} GET /senddevice/{username}/{password}/{device}/{request} return "" if not valid 3.23.25 rainy weekend create a JSON string from the SemanticMarker https://semanticmarker.org/bot/setdevice/scott@konacurrents.com/PASS/M5AtomSocket/socket/on} Create a JSON knowing the "bot" syntax, eg. setdevice/USER/PASS/device/<set>/<flag> and others like set etc. Maybe not 'dev' here. Others cmddevice/USER/PASS return: {'set':<set>,"dev': set- sends the message (command/value) to all device Supports these for now: GET /set/{username}/{password}/{command}/{value} GET /send/{username}/{password}/{request} only support 'device' ones GET /setdevice/{username}/{password}/{devicename}/{command}/{value} GET /senddevice/{username}/{password}/{device}/{request} return "" if not valid

not supported

if set then there will be more .. so add ',' if send then this is the end (no ',')

replace ' with "

Definition at line 721 of file TokenParser.cpp.

Here is the caller graph for this function:

setup_tokenParser_mainModule()

void setup_tokenParser_mainModule

(

)

setup for the token parser (really just for testing)

setup for the token parser (really just for testing)

Definition at line 659 of file TokenParser.cpp.

Here is the caller graph for this function:

stringIsQuery_mainModule()

boolean stringIsQuery_mainModule

(

char *

line

)

whether the stirng is a potential query

whether the stirng is a potential query. This can be used, but it is also used by the parseQueryLine to optimize out the original dev:name query.

Definition at line 412 of file TokenParser.cpp.

Here is the caller graph for this function:
