Go to the source code of this file.
Macros | |
| #define | NUM_PINS 2 |
| #define | NOT_TRY_ON_FIRST_FEED |
| #define | NEW_CODE_HERE |
Functions | |
| void | clearPins_HDriverStepper () |
Variables | |
| TimerDelayClass * | _timerDelayClass_HDriverStepperClass |
| HDriverStepperStepperClass More... | |
| float | _delaySeconds_HDriverStepper_setting = 0.5 |
| default .. this could be set via Preferences (TODO) More... | |
| const int | IN1_PIN = 19 |
| This works with the ESP_M5. More... | |
| const int | IN2_PIN = 23 |
| int | _freq_HDriverStepper = 10000 |
| int | _ledChannel1_HDriverStepper = 0 |
| int | _ledChannel2_HDriverStepper = 1 |
| int | _resolution_HDriverStepper = 10 |
| int | VIN_PIN = 33 |
| int | FAULT_PIN = 22 |
| int | _pins_HDriverStepperClass [NUM_PINS] |
| boolean | _isSetup_HDriverStepper = false |
Macro Definition Documentation
◆ NEW_CODE_HERE
| #define NEW_CODE_HERE |
◆ NOT_TRY_ON_FIRST_FEED
| #define NOT_TRY_ON_FIRST_FEED |
◆ NUM_PINS
| #define NUM_PINS 2 |
Definition at line 42 of file HDriverStepperClass.cpp.
Function Documentation
◆ clearPins_HDriverStepper()
| void clearPins_HDriverStepper | ( | ) |
Definition at line 50 of file HDriverStepperClass.cpp.
Variable Documentation
◆ _delaySeconds_HDriverStepper_setting
| float _delaySeconds_HDriverStepper_setting = 0.5 |
default .. this could be set via Preferences (TODO)
Definition at line 18 of file HDriverStepperClass.cpp.
◆ _freq_HDriverStepper
| int _freq_HDriverStepper = 10000 |
Definition at line 33 of file HDriverStepperClass.cpp.
◆ _isSetup_HDriverStepper
| boolean _isSetup_HDriverStepper = false |
Definition at line 75 of file HDriverStepperClass.cpp.
◆ _ledChannel1_HDriverStepper
| int _ledChannel1_HDriverStepper = 0 |
Definition at line 34 of file HDriverStepperClass.cpp.
◆ _ledChannel2_HDriverStepper
| int _ledChannel2_HDriverStepper = 1 |
Definition at line 35 of file HDriverStepperClass.cpp.
◆ _pins_HDriverStepperClass
| int _pins_HDriverStepperClass[NUM_PINS] |
Definition at line 44 of file HDriverStepperClass.cpp.
◆ _resolution_HDriverStepper
| int _resolution_HDriverStepper = 10 |
Definition at line 36 of file HDriverStepperClass.cpp.
◆ _timerDelayClass_HDriverStepperClass
| TimerDelayClass* _timerDelayClass_HDriverStepperClass |
create instance of the timer class
Definition at line 15 of file HDriverStepperClass.cpp.
◆ FAULT_PIN
| int FAULT_PIN = 22 |
Definition at line 38 of file HDriverStepperClass.cpp.
◆ IN1_PIN
| const int IN1_PIN = 19 |
This works with the ESP_M5.
Definition at line 31 of file HDriverStepperClass.cpp.
◆ IN2_PIN
| const int IN2_PIN = 23 |
Definition at line 32 of file HDriverStepperClass.cpp.
◆ VIN_PIN
| int VIN_PIN = 33 |
Definition at line 37 of file HDriverStepperClass.cpp.
